Blackmagic Design Video Assist 3G-SDI/HDMI 7" Recorder/Monitor

Pixels Per Inch

323 ppi

Image Control

Anamorphic De-Squeeze, Blue Only, False Color, Focus Peaking, Histogram, Image Flip, Picture-in-Picture, RGB Parade, Screen Markers, Vectorscope, Waveform, Zebra

Audio Input & Output

2x Mini-XLR Input
1x 1/8" / 3.5 mm Headphone Output

Embedded Audio

HDMI: 8-Channel
SDI: 16-Channel

Material

Aluminum

Video Format

SDI (10-Bit 4:2:2 YUV)
1080p: 60/59.94/50/30/29.97/25/24/23.98
1080PsF: 30/29.97/25/24/23.98
1080i: 60/59.94/50
720p: 60/59.94/50
576i: 50
480i: 59.94
HDMI (10-Bit)
1080p: 60/59.94/50/30/29.97/25/24/23.98
1080i: 60/59.94/50
720p: 60/59.94/50
576i: 50
480i: 59.94

Mount

6x 1/4"-20 Female

Media Slot

No

Battery Type

2x L-Series
No

Power Input & Output

1x Barrel (12 VDC) Input

Other Input & Output

1x USB-C
1x 2.5 mm (LANC) Input

Wi-Fi Compatibility

No

Bluetooth Compatibility

No

Input Power

12 VDC

Dimensions

7.6 x 5.14 x 1.45" / 19.3 x 13.06 x 3.68 cm

Weight

1.82 lb / 825 g
